Chief 2' x 2' Ceiling Storage Box for AV Components and Column Drop - White

The Chief ceiling storage box and column drop conceals AV equipment above a 2' X 2' ceiling tile and supports a 1.5" NPT column drop for mounting projectors within the same tile grid providing a clean professional look for classrooms and conference rooms.

Includes a high-performance, dual gang housing, isolated ground, dual receptacle outlet featuring the SurgeX non-sacrificial multi-stage filtration and surge protection system. This protects equipment from disruptive high frequency noise and damage caused by power disturbances.

ion.

• Lightweight construction, one man installation
• Plenum rated, UL approved in accordance to 2043
• Ships with speed connect installation hardware
• Overall weight capacity 100 lbs (45 kg): 50 lbs (22 kg) for projector ceiling plate, 25 lbs (11 kg) per shelf location
• AV tray supports a variety of AV components: Ships with 1 shelf, 2nd shelf sold separately see CMSUNV2, 1 RU rack rail brackets sold separately, see CMS1RU
• Built in ventilation
• Inside the plenum box or facing the room: Up to 2 single gang or 1 dual gang outlet, 4 nested knockouts for 1-1/4", 1", & �" diameter conduit
• Detachable power housing can be pre-installed with electricians on site and assembled to the storage box at a later time
• Drop carriage door improves accessibility and serviceability providing full access to equipment
• Optimal pipe flexibility within the tile helps with less reliance on image correction improving image quality
