Cisco 40GBASE-CSR4 QSFP+ Module for MMF

The Cisco 40GBASE-CSR4 QSFP+ Module is similar to the 40GBASE-SR4 interface extends supported link lengths to 300m and 400m respectively on laser-optimized OM3 and OM4 multimode fiber cables. Each 10-gigabit lane of this module is compliant to IEEE 10GBASE-SR specifications. This module can be used for native 40G optical links over 12-fiber ribbon cables with MPO/MTP connectors, or in 4x10G mode with ribbon to duplex fiber breakout cables for connectivity to four 10GBASE-SR interfaces. Maximum channel insertion loss allowed is respectively 2.6dB over 300m of OM3 cable or 2.9dB over 400m of OM4 cable.

• QSFP+ offers better usage with maximum efficiency and convenience
• With 40GBase-CSR4 technology, enjoy up to 40Gbps data transfer rate over optical fiber cable
• 40 Gigabit Ethernet for efficient data transfer and fast connectivity
• Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
• Multi-mode fiber mode support for reliable, fast transfer, sharing, and access to the data and information
• QSFP+ with data networking application/usage for maximum productivity and usability
